A kind of check valve maintaining atmospheric pressure in the space between the rupture disc and the relief valve with a pressure gaugeIt protects Rupture Disc against foreign objects or rain inflow by installed onto downstream of the Rupture Disc exposed to the atmosphereHeat shield such as cerakwool and aerogel is attached to disc and helps disc to withstand the high temperature- Applicable equipment : Silo, Bag Filter, RTO, Bucket Elevator, Duct, Hopper, etc- Fluids : Dust, Gas, Powder, Mixture- Code : NFPA 68, KOSHA CODE- Advantages %u25a0 Prompt operating in low pressure and reduction of pressure %u25a0 Fast release to minimize the damage caused by expansion gas %u25a0 Design for prevention of leakage and fragments %u25a0 Easy to replace and low maintenance cost %u25a0 Possible to select any quantity and installation location depending on the vessel size and the type of contentsExplosion Panel Features%u25a0 Safety device for preventing equipments from damage by instantaneous release of pressure and flame which were increased in the process of deflagration before gas, powder, dust and other mixtures are progressed into detonation by ignitionExplosion Panel IntroductionEXPLOSION PANELFDC BROCHURE | 36 | 37 |KSRPR(Dome Type)KSRPS(Dome Type)KSRPR(Flat Type)KSRPS(Flat Type)FlangeGasketExplosion PanelGasketChamber
